Thread: NEW MEGACHIP PLCC version for A500/2000/CDTV!

  1. #1
    Tuxbar81's Avatar
    Join Date
    Nov 2012
    Country
    France
    Region:
    Midi-Pyrénées
    Age
    52
    Posts
    1,711
    Feedback
    146 (100%)

    Exclamation NEW MEGACHIP PLCC version for A500/2000/CDTV!

    Hello,

    Here is my new version of Megachip. This is a PLCC version as you can see onto the pictures.

    With this version:
    - no need to desolder the socket of your Amiga motherboard,
    - no need to solder the Megachip onto the motherboard,
    - no need to solder the wire.

    You have just to remove the AGNUS of your Amiga, to insert the Megachip into the AGNUS socket, to connect the mini-clip onto the PIN 36 of GARY, and to change configuration of jumpers onto the Amiga's motherboard.

    It can be installed into the Amiga 500, Amiga 2000 & CTDV.


    Price: 120€ 140€ (Paypal to friend & family) excluding shipping costs.

    The price goes up to 140€ since I paid 53€/unit (shipping included) the new AGNUS instead of 20€ I paid the first lot.
    This new amount allows to compensate a part of the price rise of the AGNUS. I take the rest for my expense...

    The Megachip is sent assembled, ultrasonic cleaned and tested.

    Some members have asked for kit version. I'll take a look for this possibility.

    For NTSC AMIGA: I have no NTSC AGNUS in stock. If you are interested, you'll have to provide the AGNUS chip, or you'll have your Megachip as kit to assemble it by yourself.

    Regards,
    Franck

    Click image for larger version.

Name:	IMG_20190506_213045_resultat.jpg
Views:	663
Size:	92.3 KB
ID:	146540 Click image for larger version.

Name:	IMG_20190506_115140_resultat.jpg
Views:	757
Size:	54.5 KB
ID:	146513 Click image for larger version.

Name:	IMG_20190506_115109_resultat.jpg
Views:	756
Size:	53.8 KB
ID:	146514 Click image for larger version.

Name:	IMG_20190506_114943_resultat.jpg
Views:	671
Size:	107.7 KB
ID:	146515 Click image for larger version.

Name:	IMG_20190506_114558_resultat.jpg
Views:	691
Size:	92.4 KB
ID:	146516


    Name Quantity PM sent Paid Sent on
    Miru (USA) 1 YES YES 05/14/2019
    alke01 (Germany) 1 06/30/2019 YES 02/07/2019
    Franko (Poland) 1 06/30/2019 YES 02/07/2019
    Yulquen74 (Norway) 2 07/21/2019 YES 07/24/2019
    Doma (Norway) 1 05/12/2020
    matt020 (Australia) 1 12/12/2019 YES 12/15/2019
    Vypr (Scotland) 1 05/20/2020 YES 05/22/2020
    frost242 (France) 1 11/23/2019 YES 12/06/2019
    hlide(France) 1 05/20/2020
    Technoid (Sweden) 1 05/20/2020 YES
    unbrain (UK) 1 05/20/2020 YES 05/22/2020
    Rave (UK) 1 11/23/2019 YES 12/06/2019
    Rakeim132 (Australia) 1 11/23/2019 YES 12/07/2019
    Chatopirulo (Spain) 1 05/20/2020
    ChadsArcade (UK) 1 12/20/2020 YES 05/22/2020
    Bandaren (Sweden) + 4 KIT of non PLCC-Megachip 1
    epiceni (Italia) 1 05/25/2020 YES 07/02/2020
    ludovicfrance (France) 1 05/25/2020 YES 05/27/2020
    Corb_80 (Sweden) 1 without AGNUS (to be confirmed)
    Dano (Australia) 1 without AGNUS 07/02/2020 YES 07/04/2020
    matt020 (Australia) 1 05/25/2020
    keiko (Norway) 1 05/27/2020 YES
    ARKHAAN (France) 1 05/27/2020 YES
    ElAhrairah (Netherlands) 1 07/07/2020 YES 07/10/2020
    Last edited by Tuxbar81; 11th July 2020 at 11:29.
    Amiga Fan since 1987!
    Something wonderful has happened... My Amigas are (always) alive!
    A1000 - A1000 + IDE68K V401 - 2 x A500 + A590HD - A 600HD - A 2000 CSA 68020/68882 + A2058 + GVP A2000-HC - A 1200 HD - A 4040 - CD32 - finished GBA1000 - C64 - 1 Aros PC - Some PC under Linux

  2. #2
    Pgovotsos's Avatar
    Join Date
    Nov 2015
    Country
    United States
    Region:
    WV
    Posts
    1,428
    Feedback
    63 (100%)

    Default

    This looks very interesting. One question - does the wire have a spring clip to attach the pin, a riser socket with the wire attached that sits under the chip, or must we solder the wire? If one of the first 2 this would make this perfect for people who can't, or are uncomfortable, solder. The spring clips are super cheap and might be a the easiest solution.

  3. #3
    Tuxbar81's Avatar
    Join Date
    Nov 2012
    Country
    France
    Region:
    Midi-Pyrénées
    Age
    52
    Posts
    1,711
    Feedback
    146 (100%)

    Default

    Yes, a mini-clip is soldered at the end of the wire to allow an easy removing of the Megachip for example.
    With this solution, the only operations are config modifications of jumpers onto the Amiga motherboard.
    Amiga Fan since 1987!
    Something wonderful has happened... My Amigas are (always) alive!
    A1000 - A1000 + IDE68K V401 - 2 x A500 + A590HD - A 600HD - A 2000 CSA 68020/68882 + A2058 + GVP A2000-HC - A 1200 HD - A 4040 - CD32 - finished GBA1000 - C64 - 1 Aros PC - Some PC under Linux

  4. #4
    Pgovotsos's Avatar
    Join Date
    Nov 2015
    Country
    United States
    Region:
    WV
    Posts
    1,428
    Feedback
    63 (100%)

    Default

    Quote Originally Posted by Tuxbar81 View Post
    Yes, a mini-clip is soldered at the end of the wire to allow an easy removing of the Megachip for example.
    With this solution, the only operations are config modifications of jumpers onto the Amiga motherboard.
    Perfect for fumble fingers like mine Might want to include that in the description and a picture.

  5. #5
    Tuxbar81's Avatar
    Join Date
    Nov 2012
    Country
    France
    Region:
    Midi-Pyrénées
    Age
    52
    Posts
    1,711
    Feedback
    146 (100%)

    Default

    First post updated with picture of the Megachip with its mini-clip as suggered by Pgovotos.
    Amiga Fan since 1987!
    Something wonderful has happened... My Amigas are (always) alive!
    A1000 - A1000 + IDE68K V401 - 2 x A500 + A590HD - A 600HD - A 2000 CSA 68020/68882 + A2058 + GVP A2000-HC - A 1200 HD - A 4040 - CD32 - finished GBA1000 - C64 - 1 Aros PC - Some PC under Linux

  6. #6
    Miru's Avatar
    Join Date
    Jun 2012
    Country
    USA
    Region:
    Oregon
    Posts
    1,003
    Feedback
    30 (100%)

    Default

    Declaring interest in one if this works in PAL A 2000 as well, pm sent

  7. #7
    Tuxbar81's Avatar
    Join Date
    Nov 2012
    Country
    France
    Region:
    Midi-Pyrénées
    Age
    52
    Posts
    1,711
    Feedback
    146 (100%)

    Default

    Hi Miru,

    Yes, the Megachip works fine in PAL A2000 like mine.

    - - - Updated - - -

    PM answered.
    Last edited by Tuxbar81; 7th May 2019 at 13:03.
    Amiga Fan since 1987!
    Something wonderful has happened... My Amigas are (always) alive!
    A1000 - A1000 + IDE68K V401 - 2 x A500 + A590HD - A 600HD - A 2000 CSA 68020/68882 + A2058 + GVP A2000-HC - A 1200 HD - A 4040 - CD32 - finished GBA1000 - C64 - 1 Aros PC - Some PC under Linux

  8. #8
    74smoky's Avatar
    Join Date
    Apr 2013
    Country
    Germany
    Region:
    Ulm
    Posts
    12
    Feedback
    2 (100%)

    Default

    I would be very interested, but unfortunately this wont fit in my case.
    I own an A2000 Rev. 6.2 Board with a memory tower (Tokuda-Tower).

    As you can see in the pictures below even an icomp ACE2 wont fit.
    Attached Thumbnails Attached Thumbnails P1060743_klein.jpg   P1060744_klein.jpg
    Last edited by 74smoky; 7th May 2019 at 13:42.

  9. #9
    Tuxbar81's Avatar
    Join Date
    Nov 2012
    Country
    France
    Region:
    Midi-Pyrénées
    Age
    52
    Posts
    1,711
    Feedback
    146 (100%)

    Default

    What is the minimum height necessary so that the pcb of the megachip does not touch the small pcb soldered to the motherboard of your A2000?
    The pcb of my megachip is 5 mm above the agnus support.

    The total height of the plcc adaptor is 1 cm.

    If this is not appropriate, there is the solution of this version of Megachip:
    http://www.amibay.com/showthread.php...000-CDTV-30%80

    But in that case, it's necessary to desolder the AGNUS socket and to solder the Megachip at its place.
    Amiga Fan since 1987!
    Something wonderful has happened... My Amigas are (always) alive!
    A1000 - A1000 + IDE68K V401 - 2 x A500 + A590HD - A 600HD - A 2000 CSA 68020/68882 + A2058 + GVP A2000-HC - A 1200 HD - A 4040 - CD32 - finished GBA1000 - C64 - 1 Aros PC - Some PC under Linux

  10. #10
    74smoky's Avatar
    Join Date
    Apr 2013
    Country
    Germany
    Region:
    Ulm
    Posts
    12
    Feedback
    2 (100%)

    Default

    I measured the height of the Tokuda-Tower to 8,65 mm (to the pcb base).

    and the height of the AGNUS PLCC socket to 8,2 mm.
    Last edited by 74smoky; 7th May 2019 at 14:36.
