    Default Video repair upgrade kits for A600 A1200

    Selling composite video repair/upgrade kits for A1200 and A600. As some of you may know the bandpass filters and delay line components are custom and not sold anywhere, so if they get damaged by capacitor leak, or heat (during soldering for example) then your composite video will suffer or disappear.

    Click image for larger version.

Name:	7.jpg
Views:	282
Size:	96.6 KB
ID:	133145

    The solution is a newer and better SONY encoder chip with a small adapter PCB, that has these filters built in, so the external custom filters are not needed anymore and you can restore a decent video output. Main symptoms of external filters dying are color bleed and ghosting. On modern LCD screens the color bleed and ghosting is more noticeable, on CRT screens is less important (IMHO). Furthermore the newer SONY video chip also has S-VIDEO output so you can also solder a socket to the S-VIDEO pins if you prefer that video output type for an even better picture. This kit will also improve the composite signal somewhat - but please don't expect miracles - it'll be still a composite output.

    Before: After:
    Click image for larger version.

Name:	20180315_152224 (Medium).jpg
Views:	430
Size:	108.3 KB
ID:	133146 Click image for larger version.

Name:	20180315_151758 (Medium).jpg
Views:	409
Size:	178.0 KB
ID:	133147

    Installation:

    R1: 16K R2: 47K C1,C2: 100nF

    Remove the old chip: Not connected pads: Solder connected pads: Solder top components: Finished installation:
    Click image for larger version.

Name:	2.jpg
Views:	255
Size:	133.7 KB
ID:	133148 Click image for larger version.

Name:	3.jpg
Views:	287
Size:	144.9 KB
ID:	133149 Click image for larger version.

Name:	4.jpg
Views:	280
Size:	124.1 KB
ID:	133150 Click image for larger version.

Name:	5.jpg
Views:	296
Size:	179.7 KB
ID:	133151 Click image for larger version.

Name:	6.jpg
Views:	286
Size:	207.5 KB
ID:	133152

    PCB design is by myself (tbtorro) and the original circuit idea is by Daniel Tufvesson. You can read more about the project here. The sale is for the components and the adapter only, won't be able to provide support.

    Click image for larger version.

Name:	1.jpg
Views:	279
Size:	138.9 KB
ID:	133153

    I'm asking 12 per kit + PP fees + shipping.

    Shipping to Europe is 4.60€ unregistered parcel at your own risk. Or 17.20€ registered.

    As per forum rules: If you only write "Interested" on the thread, nothing will happen until you send a PM. You need to send a PM (Personal Message) with how many kits you need and your address exactly as it should show on the parcel.

    Feedback: Please leave feedback as per the site rules after you've received your stuff. Here is a guide how:
    http://www.amibay.com/showpost.php?p=60784&postcount=3

    Please have a look at my other new Commodore chips/parts listings:
    040-to-060-Adapter-professionally-built-060-Rev-6-CPU
    A3640-Rev-3-3-card-NEW-professionally-built
    Motorola-68060-Rev-6-(71E41J)-CPUs-NOS
    NOS-MC68030RC50C-(latest-rev)-CPUs
    Full-GAL-set-and-sockets-for-A3640-A3660-CPU-cards-NOS
    16MB-64-pin-RAM-GVP-compatible-NEW-design-with-warranty
    AGNUS-8372A-PAL-chips-(318069-02)-NOS
    Amiga-1200-original-KS-3-1-ROM-sets-NEW
    Fat-GARY-(390540-02)-for-Amiga-3000-4000-NEW-chips
    RAMSEY-(390541-07)-for-A4000-A4000T-A3000T-NEW-chips
    Super-BUSTER-chips-(390539-11)-brand-new-tested-NOS
    A3640-CPU-Cards-Rev-3-2-upgrade-chips-new
    Service-for-Amiga-4000-3000-2000-1200-600-A3640-A3630
    Last edited by tbtorro; 9th November 2018 at 16:06.
