Hiyas WhyreByter
lets analyze =)
Quote:
Originally Posted by
WhyreByter
I've got an a500 that doesn't want to wake up. Here's what it is, what I've done, and the symptoms:
okay lets lookie at what you have
Specs:
Rev 6a motherboard (good)
8372A fat agnus (good)
A501 in the trapdoor (okay)
JP2 shorted on the uppermost pads (pad 1 & 2 = good)
JP2 Pads 2 & 3 Cut (you need to do this)
JP7A open (good)
A520 video adapter (caution these can be flaky)
Quote:
Originally Posted by
WhyreByter
When I first turned it on, it showed a green screen, a pulsing power LED, and no floppy activity. The intertubes suggested either bad Chip RAM, or a faulty Agnus, with reseating the Agnus as the possible fix. Tried it without the a501, and the same result.
This is the classic memory assertion failure - there is a base conflict of address.
While "anti-static" precautions are a good practice its important to know that the Agnus is not a static sensitive device.
Quote:
Originally Posted by
WhyreByter
Tried it again, and this time there's no screen at all. My TV says "No Signal", so I believe it's not just a black screen, but who knows when a 20+ year old machine is trying to talk to the new kid TV. :)
Tried it with/without the a501, different, known good PS, verified the a520 is working well (used it on a known good a1200). So, I'm not sure if I made a bad situation worse, or if it was just a goner to begin with. :(
Unfortuantely the system cannot lock a base address - hence the LED flashing.
This can happen with a bad GARY or Agnus - but in this case I think its because it has a a conflict on Address 19 and 20 (JP2)
Quote:
Originally Posted by
WhyreByter
I'd like to get it working, and pass it along to someone who will use it (my a1200 suits me well, I just wanted to rescue this thing). Any suggestions on where to start troubleshooting it? My gut is "replace everything that's socketed", but I don't have a spare a500 to do that...
Thanks!
WhyreByter
Okay -
Firstly you need to cut the trace between 2 and 3 of JP2 - ensure that this is cut by using a multimeter in continuity mode
Ensure that all the pads of JP7A are also isolated from each other by again testing continuity between the pads
Here is a quick how to (click for images to Zoom)
Schematic
http://s2.postimage.org/1kt1shqjo/A500_6a_1_MBCHIP.png
JP2
http://s2.postimage.org/1kt53kfj8/jp2_zoom.jpg
JP7A
http://s2.postimage.org/1kt3g131g/jp7a_zoom.jpg
With the Rev6A you can populate the motherboard with 4x (256x4) -80ns Chips =D
remember, that by populating the motherboard you will be rendering the trapdoor unusable. To be fair modifying EXRAM (JP7A already does this anyway)
Good luck, hope this ramble helps =)
