    Post AA3000+ Amiga 3000 AGA motherboard PCBs

    I'm organizing a group order for the AA3000+ PCBs.
    You can find more about the AA3000+ motherboard project here.

    I am only providing blank PCBs, you need to assemble the boards yourself or ask someone to assemble them for you.

    Buyer will get the following:
    - a blank AA3000+ motherboard PCB
    - a blank AA3000+ Firebird PCI daughterboard PCB
    - bill of materials
    - pre-filled Mouser shopping cart (contains ~90% of all components for both boards)
    - JEDEC files
    - PCB Explorer for assembling the PCBs

    The rest of the components you need to purchase from somewhere else are:
    - Amiga custom chips, SCSI chip, PAL/NTSC oscillator
    - 68030 CPU, 68881/68882 FPU
    - ADV101KP30 Video DAC, NE564
    - memory chips for Chip RAM and scandoubler / flicker fixer
    - RP5C01 RTC chip
    - A3000/A4000 CPU slot connector
    - DSUB 23-pin connectors (1x male, 1x female)
    - Altera EPM7128SQC160-15 chips
    - AT&T DSP3210 or Lucent DSP3210 (optional)

    I'm also offering a component set for the boards:
    - ADV101KP30 Video DAC
    - Chip RAM memory chips (4x chips)
    - RP5C01 RTC chip

    In order to get the PCBs, do the following:
    1. Declare your interest here.
    2. Send me a PM asking for payment details.
    3. Send the payment within 48 hours after receiving the payment details to secure your position in the queue.

    Orders have to be paid in advance.

    Price for the PCBs is 125 EUR.

    Tracked shipping without insurance to Europe is 30 EUR, rest of the world 50 EUR.
    Tracked shipping with insurance to Europe is 45 EUR, rest of the world 55 EUR.

    Shipment without insurance is at buyers risk.

    Shipping to Europe is 35 EUR, rest of the world is 45 EUR.

    Price for the component set is 25 EUR.
    No component sets left for sale.

    Payment by PayPal or bank transfer.

    The PCBs will be black with gold finish. There is no minimum order for the group buy, the PCBs will be ordered even if there is only one person interested.
