EP8700 5Tap TTL Compatible High Speed Active Delay Lines DIP8?

Woz

Member
Joined
Nov 4, 2016
Posts
211
Country
UK
Region
Carmarthenshire
Since the EP8700 chips are so expensive, retailing at $42-£30 currently on eBay I was searching for a cheaper alternative. Dallas DS1000 - 50 at $4.79-£3.38, would this work by removing the pins marked as NC = Not Connected pins 2, 3, 5, 9, 11 and 13?
EP8700 chip.jpgDALLAS DS1000 - 50.jpg

Last edited:
Looking at the datasheets it would work but you would need the DS1000-25 to replace the EP8700 NOT the -50. The EP8700 has a total delay of 25 ( 5 for each point ) as does the DS1000-25. The DS1000-50 has a total delay of 50 (10 for each point).

Please let me know how you get on as this could help others!

Last edited:
I can confirm a DS1000-25 is compatible. I have just put one in my A3640 Rev 3.2 mod + NoWaitState mod board and the system appears to be operating correctly.
