For Sale A4000D PCBs with bird seeds and upgrades

  • Thread starter Thread starter saft6luck
  • Start date Start date
  • Replies Replies 20
  • Views Views 2156
S

saft6luck

Active member
AmiBayer
Rating - 100%
46   0   0
Joined
Nov 7, 2023
Posts
158
Country
Germany
Region
Bavaria
These A4000D boards are part of the third batch which I did to test the ENIG coating. They are based on Acill's A4000D board and have the following upgrades integrated:
  • Markings added for jumper, chipset, sockets, logic, all resistors, capacities etc.
  • Drill holes are changed to real holes instead of vias, L500 and many, many more small fixes applied
  • 2MB Chipram on the PCB (74F841 not needed anymore)
  • BIGROM integrated (see A4000T), allows for 1MB Kickstart, compatible with original ROMs; can be deleted via resistors
  • RAM Extension integrated: up to 112MB Fastram
    SIMM size configurable via jumper: 1MB up to 64MB SIMMs, max. 112MB Fastram; can be deleted via resistors
  • RAM BANK0 und BANK2 can take double sided modules now, e.g. 2x32MB (= 4x16MB) or 1x128MB (= 2x64MB)
  • 8MB Chipmem options are removed -> saves 2 ICs and removes 2 useless jumpers
  • Kickrom with 42 Pins and integrated Kickstart switch
  • RTC Diode fix integrated, 2032 batterie socket + diode
  • Dedicated NMI and power up RESET connectors
  • Useless "Option"-jumpers removed (1x 74HCT166 not needed anymore)
  • Delay-line with 14 pins or 8-pin SMD version
  • 4-pin fan connectors: 2x12V, 1x5V
  • H- und V-sync buffer for the 23-pin connector; can be deleted
  • Power supply via jumper for IDE DoMs or CF adapters
  • Side holes for the stacked connector are fixed to work with up-to-date connectors from e.g. mouser (old style still works) - similar for cinch connectors
It took me ~8h to build one board, just using the markings on the board. Normal A4000D and/or A4000Cr build instructions also work fine.
The board is tested with BFG9060 + 112MB Fastram, original A3400 (68030) and Z3660.
The following Zorro cards are tested as reference: ZZ9000, Buddha IDE, Deneb, XSurf 100 with RR, Piccolo SD64 und Re4091.

There are still 6 4 1 PCBs available.

PCBs are available on request as I regularly order new PCBs for my developments.

One PCB is 192€ + shipping via DHL, for Germany included, most EU countries 9,50€, all others on request.

Payment possible via Paypal F&F or in EU also via IBAN.

Also part of the delivery are the files for the GALs, a manual, the BOM for the missing parts and a Mouser basket for all parts which are available there.

If interested, I can include the chipram for 16€ and/or 2 used, but fully working MX29F1615 flash chips (-> 4x 1MB Kickstart) with e.g. DiagRom for 5€.

IMG_2500 klein.jpgIMG_2501 klein.jpg

This is an example of the build of the previous batch (mouse/joystick cover from Ordyne):

IMG_2383 klein.jpg

Example of 64MB Fastram using 32MB SIMMs:


Attachments

Last edited:
Declaring interest.
(Marked as sold/completed by saft6luck)

Last edited by a moderator:
Declaring interest.
Declaring interest, including Chip ram option. Shipping to New Zealand. Paypal F&F
(Marked as sold/completed by saft6luck)

Last edited by a moderator:
Fatcat said:
Declaring interest.
Declaring interest, including Chip ram option. Shipping to New Zealand. Paypal F&F
(Marked as sold/completed by saft6luck)
Click to expand...

PCB arrived today after a 2 week journey to New Zealand. Very well packed / damage free and prompt shipping. Thanks. Feedback left.

Got my new A4K board, the old board is ready to harvest, Mouser BOM order and tbtorro's 200 pin Connectors arrived. Now to find sometime time.



Declaring interest.
Declaring interest in one, with Chipram and flash chips. Been trying to fix up my OG board but can’t get Z-III working so time to take the plunge and rebuild!

PM incoming.
(Marked as sold/completed by saft6luck)

Last edited by a moderator:
Declaring interest.
Declaring interest plus chipram and diagrom
(Marked as sold/completed by saft6luck)

Last edited by a moderator:
saft6luck said:
These A4000D boards are part of the third batch which I did to test the ENIG coating. They are based on Acill's A4000D board and have the following upgrades integrated:
  • Markings added for jumper, chipset, sockets, logic, all resistors, capacities etc.
  • Drill holes are changed to real holes instead of vias, L500 and many, many more small fixes applied
  • 2MB Chipram on the PCB (74F841 not needed anymore)
  • BIGROM integrated (see A4000T), allows for 1MB Kickstart, compatible with original ROMs; can be deleted via resistors
  • RAM Extension integrated: up to 112MB Fastram
    SIMM size configurable via jumper: 1MB up to 64MB SIMMs, max. 112MB Fastram; can be deleted via resistors
  • RAM BANK0 und BANK2 can take double sided modules now, e.g. 2x32MB (= 4x16MB) or 1x128MB (= 2x64MB)
  • 8MB Chipmem options are removed -> saves 2 ICs and removes 2 useless jumpers
  • Kickrom with 42 Pins and integrated Kickstart switch
  • RTC Diode fix integrated, 2032 batterie socket + diode
  • Dedicated NMI and power up RESET connectors
  • Useless "Option"-jumpers removed (1x 74HCT166 not needed anymore)
  • Delay-line with 14 pins or 8-pin SMD version
  • 4-pin fan connectors: 2x12V, 1x5V
  • H- und V-sync buffer for the 23-pin connector; can be deleted
  • Power supply via jumper for IDE DoMs or CF adapters
  • Side holes for the stacked connector are fixed to work with up-to-date connectors from e.g. mouser (old style still works) - similar for cinch connectors
It took me ~8h to build one board, just using the markings on the board. Normal A4000D and/or A4000Cr build instructions also work fine.
The board is tested with BFG9060 + 112MB Fastram, original A3400 (68030) and Z3660.
The following Zorro cards are tested as reference: ZZ9000, Buddha IDE, Deneb, XSurf 100 with RR, Piccolo SD64 und Re4091.

There are still 6 4 1 PCBs available.

PCBs are available on request as I regularly order new PCBs for my developments.

One PCB is 192€ + shipping via DHL, for Germany included, most EU countries 9,50€, all others on request.

Payment possible via Paypal F&F or in EU also via IBAN.

Also part of the delivery are the files for the GALs, a manual, the BOM for the missing parts and a Mouser basket for all parts which are available there.

If interested, I can include the chipram for 16€ and/or 2 used, but fully working MX29F1615 flash chips (-> 4x 1MB Kickstart) with e.g. DiagRom for 5€.

View attachment 2491034View attachment 2491035

This is an example of the build of the previous batch (mouse/joystick cover from Ordyne):

View attachment 2491068

Example of 64MB Fastram using 32MB SIMMs:
View attachment 2491072
Click to expand...

nickrb said:
Declaring interest.
Declaring interest plus chipram and diagrom
(Marked as sold/completed by saft6luck)
Click to expand...
I really like seeing progress on getting updates done to my boards. I'd like it even more if the official repo got changes added back into it as well. It's a shame all the progress isn't getting back in with a few exceptions. I know of several branches all working independent now. This wasn't my original intention on making everything public.

Acill said:
I really like seeing progress on getting updates done to my boards. I'd like it even more if the official repo got changes added back into it as well. It's a shame all the progress isn't getting back in with a few exceptions. I know of several branches all working independent now. This wasn't my original intention on making everything public.
Click to expand...

That's right but it also needs time to update and test these changes. If you want to participate there, you are free to join.

There will be a version soon, which you can get to review and even update your repo.

But I don't think this is the right way to communicate your dislikes. You know where to catch me. And personal communication should do the trick.

Last edited:
saft6luck said:
That's right but it also needs time to update and test these changes. If you want to participate there, you are free to join.

There will be a version soon, which you can get to review and even update your repo.

But I don't think this is the right way to communicate your dislikes. You know where to catch me. And personal communication should do the trick.
Click to expand...

I'd love to, but currently I am away on work travel. I can still check in some though. I also replied to the discord message you sent me.
